Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router - Image 2

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router - Image 3

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router - Image 4

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router - Image 5

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router - Image 6

Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router

$383.35 inc GST

(0 customer reviews)

Ruijie Reyee RG-EG105GW-X is an AX3000 Wi-Fi6 Wireless All-in-One Business Router.

Professional and high-performance Wi-Fi 6 business VPN router.
Easy network construction with all-in-one wireless router.
One-Click Reyee Mesh.
Diverse enterprise-level features for different service scenarios.
Securely monitoring the NVR/IPC/internal server anytime from anywhere.

Availability: 21 in stock

Add To Wishlist

SKU: RG-EG105GW-X Categories: Smart WiFi Routers, WiFi Mesh Systems for Seamless Whole-Home Coverage Tags: Cloud Managed Router, Mesh, Wi-Fi 6

Loading...

Key Specification

Product Type	Wi-Fi 6 all-in-one wireless router	Wireless Standard	Wi-Fi 6 (IEEE 802.11ax), compatible with IEEE 802.11a/b/g/n/ac
Max Wireless Rate	2974 Mbps	Gigabit Ports	5 x 10/100/1000BASE-T
Fixed WAN Ports	1	Fixed LAN Ports	1
CPU	Dual-core processor, 1.3 GHz	RAM / Flash	512 MB DDR3 / 128 MB SPI NAND Flash
Dimensions (W x D x H)	283 mm x 172 mm x 46 mm (11.14 in. x 6.77 in. x 1.81 in.), excluding antennas and foot pads	Weight	1.2 kg (2.65 lbs.), without packaging materials
Mounting	Desk	Operating Temperature	0 deg C to 40 deg C (32 deg F to 104 deg F)
Recommended Clients	160 clients	Warranty	3 years

Feature Images

Official product promotional feature images.

RG-EG105GW-X official feature image 1

RG-EG105GW-X official feature image 2

RG-EG105GW-X official feature image 3

RG-EG105GW-X official feature image 4

Product Video

Open box video for Ruijie Reyee RG-EG105GW-X Wi-Fi 6 AX3000 High-performance All-in-One Wireless Router.

RG-EG105GW-X Open Box Video

Deployment Support

Clear product positioning with Star-Link Group support separated from manufacturer product features.

Cloud Managed

Suitable for business networking projects where easier deployment and remote management are important.

Project Ready

Prepared for installers, integrators and trade customers comparing hardware across network projects.

Consistent Layout

Uses the same clean Star-Link Group product-page layout for easier comparison.

Available project support from Star-Link Group:

Free pre-configuration for your first project, and for projects involving five or more devices. Free consultation and after-sales support.

Note: Pre-configuration service is provided by Star-Link Group and is not a built-in feature of this product. Please email support@star-link.net.au if you would like to discuss your setup.

Weight	1.93 kg
Dimensions	42 × 37 × 7 cm
Radio	Dual-stream dual-band
Protocol	Concurrent 802.11ac wave2, wave1, 802.11a/b/g/n
Operating Bands	802.11a/n/ac: 5G: 5.150~5.350GHz, 5.725~5.850GHz, 802.11b/g/n: 2.4G ~ 2.4835GHz
Antenna	Array antennas (2.4G: 2dBi, 5G: 2dBi)
Spatial Streams	2.4G 2x2MIMO 5G 2x2MIMO
Max Throughput	1.267Gbp per AP, Up to 400Mbps at 2.4G, Up to 867Mbps at 5G
Modulation	DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps, MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM, Modulation OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
Receiver Sensitivity	11a/g: -89dBm (6Mbps), -80dBm (24Mbps), -76dBm (36Mbps), -71dBm (54Mbps), 11ac HT20: -83dBm (MCS0), -57dBm (MCS9), 11ac HT40: -79dBm (MCS0), -57dBm (MCS9), 11ac HT80: -76dBm (MCS0), -51dBm (MCS9), 11b: -91dBm (1Mbps), -88dBm (5Mbps), -85dBm (11Mbps), 11n: -83dBm@MCS0, -65dBm@MCS7, -83dBm@MCS8, -65dBm@ MCS15
Maximum Transmit Power	2.4~2.4835GHz: ≤20dBm (EIRP), 5.150~5.350GHz: ≤20dBm (EIRP), 5.725~5.850GHz: ≤20dBm (EIRP)
Adjustable Power	1dBm
Dimensions	194mm×194mm×35mm (excluding mounting kits)
Weight	0.45kg (excluding mounting kits)
Service Ports	2 10/100Base-T Ethernet ports, PoE/LAN1 port supports PoE, Service Ports 2 10/100/1000Base-T Ethernet ports, PoE/LAN1 port supports PoE
Management Port	NA
LED Indicator	Single indicator (green light)
Power Supply	Local power supply, DC 12V/1.5A (Note: The power adapter is sold as an optional accessory) 802.3af/802.3at PoE
Power Consumption	≤ 12.95W
Environment	Operating humidity: 5%~95% (non-condensing), Operating temperature: 0°C~40°C, Storage humidity: 5%~95% (non-condensing), Storage temperature: -40°C~70°C
Installation	Wall-mount, ceiling-mount
Safety Standard	GB4943, IEC 60950-1
EMC Standard	GB9254, EN301 489, EN50155, EN50121, EN55032, EN61000, EN55035
Vibration Standard	IEC61373
Radio Standard	SRRC certification, EN300 328, EN301 893
MTBF	>400000H
Operating Mode	AP mode and routing mode
WLAN	Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID, Maximum number of clients: 110, Recommended number of clients: 40 (8 at 2.4GHz, 32 at 5GHz), SSID-based and radio-based STA limit, Support Layer 2 user isolation, Support SSID hiding, Up to 8 SSIDs
Roaming	Support Layer 2 and Layer 3 roaming
Security	Support PSK authentication, Support static blacklist and whitelist, Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption
Routing	Support static IP address, DHCP, PPPoE Dial Up
Management and maintenance	Support local management with web, Support local or remote management with Ruijie Cloud app, Support remote management with Ruijie Cloud platform, Support unified networking of all network equipment
Platform management features	Automatic RF adjustment via the platform, Unified configuration via the platform, Unified monitoring via the platform
